D2-EC(SA)
Suitable for Surgery and Dentist
PRODUCT DESCRIPTION
D2-EC(SA) Treatment Unit - Optimally suited for left and right-handers -
Treatment chair: Highest position: 730 mm / Lowest position: 395 mmDoctor’s device on a freely movable base with Bottle Care System: The touch screen guarantees intuitive operation. The user interface can be individually configured. It can be used for endodontics at the touch of a button. Integrated flushing function for all user parts, for up to 6 users, storage for 2 standard trays, operation via touch screen or hands-free via wireless foot controller. The documentation function allows you to conveniently store all implant insertion values on a USB stick.
Available with white or anthracite casings.
EQUIPMENT Standard
- Stainless-steel structure
- Comfort upholstery
- Low-noise chair movement with soft start and stop
- 5 chair positions can be stored
- Automatically folding leg rest for easy entry and exit of the patient
- Suitable for left and right-handers due to a combination of doctor‘s device with touchscreen on a freely movable base with Bottle Care System and a 239° swivelling assistant‘s device with saliva ejector and spray mist suction
- Wireless foot controller
EQUIPMENT Optional
- Left and/or right arm rest
- Height-adjustable tray
- Holder for waste container on the tray
- LED operating lamp
- 3-function syringe in the assistant’s device
- 2nd saliva ejector in the assistant’s device
- Suction system integration only possible with wet suction
- Standard turbine connection or Advanced-Air turbine
- EM-12 L micromotor(s)
- Piezo scaler
- 3-function syringe (Mounted optionally on left or right side)
- ImplantmedPlus (Coolant pump with ImplantmedPlus motor EM-19 LC)
- Coolant pump with preparation for ImplantmedPlus motor EM-19 LC
ERGONOMICS CONCEPT D2-RANGE
![](https://b2b.dkl.de/media/9f/3c/03/1618905257/Ergonomie%20Serie%20D2.png)
- The ergonomically combined movement of seat and back rest allows to move the patient comfortably into the treatment position. No compression or stretching effects.
- Automatically folding leg rest for easy entry and exit of the patient.
- Double-jointed head rest. The head inclination is infinitely adjustable.
- Optimal working posture thanks to sufficient legroom.
INDIVIDUAL COLOR SELECTION FOR YOUR UPHOLSTERY
A wide choice of colours!
DKL imitation leather is biocompatible and
complies with the DIN EN ISO 10993 standard.
![](https://b2b.dkl.de/media/9a/d0/83/1650552168/Farben_kurz.png)
![](https://b2b.dkl.de/media/5a/2b/01/1650552171/Farben_lang.png)
![](https://b2b.dkl.de/media/fb/fb/73/1618904228/D2-EC%28SA%29%20rechts.png)
Faq
For which patient weight are DKL treatment chairs approved?
Our treatment chairs of the L2-Range and D2-Range are approved for a patient weight of 150 kg.
